| | GMC2016 | GMC2516 |
| Work table size (width × length) (mm) | 1300*2000 | 1300*2000 |
| Stroke in the moving direction of the table (X-axis mm) | 2000 | 2500 |
| Stroke in the moving direction of the spindle carriage (Y-axis mm) | 1650(tool change stroke 1850) | 1650(tool change stroke 1850) |
| Stroke in the up and down movement direction of the spindle (Z axis mm) | 800 | 800 |
| Gantry width (mm) | 1660 | 1660 |
| Gantry is too high (mm) | 1100 | 1100 |
| Distance from spindle end face to work table (mm) | 250-1050 | 250-1050 |
| Table T-slot (number - size x spacing) | 7-22×170 | 7-22×170 |
| Spindle Specifications (Model/Installation Diameter) | BT50/Φ190 | BT50/Φ190 |
| Spindle transmission mode | belt | Speed 6000r/min | Speed 6000r/min |
| The transmission ratio of the pulley is standard 1.5:1; (optional 1:1) | The transmission ratio of the pulley is standard 1.5:1; (optional 1:1) |
| ZF deceleration + belt (optional) | The speed is 6000r/min and the transmission ratio is 4:1; | The speed is 6000r/min and the transmission ratio is 4:1; |
| Gear Head (Weimars) | Maximum speed 6000r/min Transmission ratio 4.4:1 | Maximum speed 6000r/min Transmission ratio 4.4:1 |
| Rapid traverse feed rate (m/min) | 15 | 15 |
| Cutting feed rate (m/min) | 10 | 10 |
| X, Y, Z axis ball screw specifications/pitch | X: 6310, Y: 5010, Z: 5010 | X: 6312, Y: 5010, Z: 5010 |
| X, Y, Z axis guide rail specifications / number of sliders | X axis: roller guide 55/6; | X axis: roller guide 55/8; |
| Y axis: roller guide 55/4; | Y axis: roller guide 55/4; |
| Z axis: rectangular slide | Z axis: rectangular slide |
| X, Y, Z axis servo motor transmission mode and transmission ratio | X, Y, Z axes are directly connected | X, Y, Z axes are directly connected |
| Spindle motor selection recommendation | 22kW wide area motor | 22kW wide area motor |
| X, Y, Z three-phase servo motor recommendation | ≥ X: 38N m; Y: 30N m; Z: 30N m (brake) | ≥ X: 38N m; Y: 30N m; Z: 30N m (brake) |
| Optical machine dimensions | 5590*3630*3830 | 6590*3630*3830 |
| (length × width × height) (mm) |
| Workbench load (t) | 4 | 5 |
| Light machine weight about (t) | 16 | 18 |
